Lillbacka Heavy Duty King Crimper KC Series
Lillbacka Heavy Duty King Crimper KC Series
Note:
The Specifications and information above-mentioned may be changed without prior notice.
Technical Specifications
Lillbacka Heavy Duty King Crimper KC Series
| Model | Unit | KC800 | KC 1200 | KC2000 |
| Max crimping dia | mm | 640 | 640 | 640 |
| Max crimping dia with master dies | mm | 650 | 650 | 650 |
| Max. crimping force | kN | 8000 | 12000 | 20000 |
| Max. crimping force | tonnage | 800 | 1200 | 2000 |
| Cycle time 10 mm | (s)² | 3.2 | 5.2 | 7.7 |
| Hydraulic hose size | inch | 16 * | 16 * | 16 * |
| Industrial hose size | inch | 25.20 * | 25.20 * | 25.20 * |
| Max. opening | mm | 180 | 180 | 180 |
| Max. opening without dies | mm | 820 | 820 | 820 |
| Master Die D/L | mm | 640/300 | 640/300 | 640/300 |
| Master die D/L | inch | 25.20/11.8 | 25.20/11.8 | 25.20/11.8 |
| Oil tank volume | L | 250 | 250 | 250 |
| Machine Dimension | mm | 2825 x 1345 x 2040 | 3015 x 1345 x 2291 | 3380 x 1345 x 2361 |
| Hydraulic Dimension | mm | 1195 x 705 x 1411 | 1195 x 705 x 1411 | 1195 x 705 x 1411 |
| Machine Weight | kg | 9680 / 22046 | 12000 / 27116 | 15500 / 32628 |
| Hydraulic Unit Weight | kg | 305 / 772 | 305 / 772 | 305 / 772 |
Features
| The King Crimper’s extremely large opening and enormous crimping force coupled with the world’s most advanced crimping control means there are literally no limitations to what it can crimp |
| The King Crimper’s robust frame design ensures consistent repeatability. |
| The ICC Control on a swing arm and remote control device allows the operator to crimp hard to crimp objects and while keeping them safe and in control of the process. |
| The primary markets for ‘the King’ are oil & gas and transportation for crimping pipes, tubes and fittings |
| Camera with display as a standard feature |
| Maximum opening is the total die travel. |
| Add this value to the minimum crimping diameter of the die set used. The result is the maximum opening of the machine with die set in place |
