Technical Specifications
DN Solutions Vertical Machining Center Machine DMP Series
| Description | Unit | DMP 500-2SP | DMP 570/50-2SP | |
| Travel(Stroke) | X-axis | mm (inch) | 1040 (40.9) | 600 (23.6) |
| Y-axis | mm (inch) | 520 (20.5) | 570 + 142(gantry ready) (22.4 + 5.6) | |
| Z-axis | mm (inch) | 600 (23.6) | Z1 : 625 (24.6) Z2 : 625 (24.6) | |
| Distance between spindles | mm (inch) | 400 (15.7) | 500 (19.7) | |
| Feedrate(Rapid Traverse) | X axis | m/min (ipm) | 40 (1574.8) | 40 (1574.8) |
| Y axis | m/min (ipm) | 40 (1574.8) | 40 (1574.8) | |
| Z axis | m/min (ipm) | 36 (1417.3) | 36 (1417.3) | |
| Table | Table size | mm (inch) | 1200 x 520 (47.2 x 20.5) | 1500 x 570 (59.1 x 22.4) |
| Max. Load | kg (lb) | 800 (1763.7) | 1100 (2425.0) | |
| Table type | T-SLOT (4-125 (4.9) x 18 (0.7) H7) | T-SLOT (4-125 (4.9) x 18 (0.7) H8) | ||
| Spindle | Max spindle speed | r/min | 12000 {8000}* | 8000 |
| Spindle taper | ISO #40 | ISO #50 | ||
| Max. torque | N·m (ft-lb) | 117.8 {286}* (86.9 {211.1}) | 286 (211.1) | |
| Automatic Tool Changer (ATC) | Max diameter | Continous mm (inch) | 90 {80, 75}* (3.5 {3.1, 3.0}) | 125 (4.9) |
| Without Adjacent Tools mm (inch) | 150 (5.9) | 220 (8.7) | ||
| Capacity | ea | 2-24 {2-30, 2-40}* | 2-24 | |
| Power Consumption | kVA | 60 | 60 | |
| Machine size | Height | mm (inch) | 3510 (138.2) | 3680 (144.9) |
| Length | mm (inch) | 2400 (94.5) | 2400 (94.5) | |
| Width | mm (inch) | 2760 (108.7) | 3200 (126.0) | |
| Machine Weight | kg (lb) | 8500 (18739.0) | 13000 (28659.7) |
*NOTE*The Specifications and information above-mentioned may be changed without prior notice. For more details, please contact ELECTRONICA
