Product description
For more details, please contact marketing@electronicahitech.com
Honor CNC Vertical Lathe
Honor CNC Vertical Lathe
Note:
The Specifications and information above-mentioned may be changed without prior notice.
Technical Specifications
Honor VTL 125-200-250 Series
| Particular | Unit | VL-125C | VL-125CM | VL-160C | VL-160CM | VL-200C | VL-200CM | VL-250C | VL-250CM |
| Max.swing dia | mm | 1600 | 2000 | 2500 | 3000 | ||||
| Max.turning dia | mm | 1600 | 2000 | 2500 | 2970 | ||||
| Max.turning height | mm | 1200 | 1170 | 1200 | 1170 | 1480 | 1480 | ||
| Table Diameter | inch/mm | 1250 | 1600 | 2000 | 2500 | ||||
| Range Table Speed | rpm | 1-300 | 1-250 | 1-200 | 1-160 | ||||
| Cross Section of ram | mm | 220x220 | 220x220 250x250 | 220x220 | 220x220 250x250 | 250x250 | 250x250 | 250x250 | 250x250 |
| Power Requirement | kVA | 75 | 90 | 75 | 90 | 90 | 105 | 90 | 105 |
| Floor Space ( L * W) | mm | 6540 X 4400 | 6880 X 4400 | 7000 X 4725 | 7350 X 4725 | 7970 X 5532 | 8840 X 5532 | 8295 X 5564 | 8580 X 5564 |
| Max Height | mm | 5330 | 5670 | 5350 | 5700 | 6470 | 6805 | 6470 | 6805 |
| Max Weight | kg | 24500 | 25300 | 30600 | 31400 | 50000 | 51000 | 63000 | 64000 |
Features
| Casted column & Table base |
| appriciated by Automotive/petrochemical inductries |
| Customized Special solutions for Break Drum, Fly Wheel, Break Disc, Hub etc. |
| Single casted Bax way design of guides |
| High Precision, Durability & Productivity. |
