Yawei Laser Cutting HLE Series
Yawei Laser Cutting HLE Series
Note:
The Specifications and information above-mentioned may be changed without prior notice.
Technical Specifications
Yawei Laser Cutting HLE Series
| Model | Unit | HLE-1530 | HLE-1560 | HLE-2040 | HLE-2060 | HLE-2560 | HLE-2580 | HLE-25100 | HLE-25120 |
| Cutting range | mm | 3000 × 1500 | 6000 × 1500 | 4000 × 2000 | 6000 × 2000 | 6000 × 2500 | 8000 × 2500 | 10000 × 2500 | 12000 × 2500 |
| X axis stroke | mm | 3040 | 6040 | 4040 | 6040 | 6040 | 8040 | 10040 | 12040 |
| Y axis stroke | mm | 1520 | 1520 | 2020 | 2020 | 2520 | 2520 | 2520 | 2520 |
| Z axis stroke | mm | 240 | 240 | 240 | 240 | 300 | 300 | 300 | 300 |
| X/Y maximum trajectory speed | m/min | 140 | 140 | 140 | 140 | 140 | 140 | 140 | 140 |
| X / Y maximum acceleration | m/s² | 1.5G | 1.5G | 1.5G | 1.5G | 1.5G | 1.5G | 1.5G | 1.5G |
| Positioning accuracy | mm | ±0.03 | ±0.03 | ±0.03 | ±0.03 | ±0.03 | ±0.03 | ±0.03 | ±0.03 |
| Repositioning accuracy | mm | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 |
| Maximum load of worktable | kg | 700 | 700 | 1400 | 2000 | 3000 | 4000 | 5000 | 6000 |
| Machine layout dimension | mm | 8700 × 4800 × 2150 | 15500 × 4800 × 2150 | 11000 × 5000 × 2150 | 15500 × 5000 × 2150 | 15500×5500×2150 | 20000 × 5500 × 2150 | 23500 × 5500 × 2150 | 28000 × 5500 × 2150 |
| Machine weight | kg | 8000 | 12000 | 10000 | 14000 | 20000 | 25500 | 30000 | 36000 |
| Laser generator power | kw | 1 / 1.5 / 2 / 3 / 4 / 6 | |||||||
Features
| High Performance and low cost |
| Using bright surface cutting technology,fast cutting speed, small slope, low roughness |
| Gantry double-drive high-rigidity bed structure, annealing and stress-relieving operation to ensure efficient and stable running |
| Handy operation |
