Yawei Laser Cutting HLA Series
Yawei Laser Cutting HLA Series
Note:
The Specifications and information above-mentioned may be changed without prior notice.
Technical Specifications
Yawei Laser Cutting HLA Series
| Model | Unit | HLA-1530 | HLA-2040 | HLA-2060 | HLA-2560 | HLA-2580 | HLA-25120 |
| Cutting range | mm | 3000 × 1500 | 4000 × 2000 | 6000 × 2000 | 6000 × 2500 | 8000 × 2500 | 12000 × 2500 |
| X axis stroke | mm | 3040 | 4040 | 6040 | 6040 | 8040 | 12040 |
| Y axis stroke | mm | 1520 | 2020 | 2020 | 2520 | 2520 | 2520 |
| Z axis stroke | mm | 120 | 120 | 120 | 120 | 120 | 120 |
| X/Y maximum trajectory speed | m/min | 140 | 140 | 140 | 140 | 140 | 140 |
| X / Y maximum acceleration | m/s² | 1.2G | 1.2G | 1.2G | 1.0G | 1.0G | 1.0G |
| Positioning accuracy | mm | ±0.03 | ±0.03 | ±0.03 | ±0.03 | ±0.03 | ±0.03 |
| Repositioning accuracy | mm | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 | ±0.02 |
| Maximum load of worktable | kg | 700 | 1200 | 2000 | 3000 | 4000 | 6000 |
| Machine layout dimension | mm | 4550 × 4500 × 2000 | 5550 × 5000 × 2000 | 8500 × 5000 × 2000 | 8500 × 5500 × 2100 | 11000 × 5500 × 2100 | 15500 × 5500 × 2100 |
| Machine weight | kg | 5000 | 6000 | 8000 | 14000 | 18000 | 23000 |
| Laser generator power | kw | 1 / 1.5 / 2 / 3 / 4 / 6 | |||||
Features
| Open gantry double drive, single table structure, stable performance |
| The plate welding frame is matched with the aluminum alloy beam to meet the requirements of high acceleration motion |
| Separate electric control cabinet can adapt to the spatial arrangement of different venues |
