Hartford Gantry Type 5 Axis Machining Center 5A Series

Technical Specifications

Model	Unit	5A-40R	5A-65E	5A-65EF	5A-95QX/5X
Working Surface	mm	320	650	650	800
Max Load	kg	Horizontal : 200 Tilt :100	500	500	850
T Slot Width	mm	12H7	18 X 6 X 60	18 X 6 X 60	14 X 7X 100
X Axis	mm	410	650	650	950
Y Axis	mm	610	520	520	850
Z Axis	mm	510	460	460	650
Distance b/w Spindle to Table Center	mm	125-635	150-610	150-610	100-750
Spindle nose taper		ISO40	ISO40, HSK -A63(24K Only )	ISO40, HSK -A63(24K Only )	ISO40, HSK -A63
Spindle Speed (DDS)	rpm	12000 (opt 10000/ 15000)	# 40 10000 (opt 12000/ 15000)	# 40 10000 (opt 12000/ 15000)	# 40 10000 (opt 12000/ 15000)
Spindle Speed (Built-In)	rpm	-	#40 opt. 24000	#40 opt. 24000	opt. 20000
Cutting Feedrate	m/min	20 / 20 /20	20 / 20 /20	20 / 20 /20	20 / 20 /20
Rapid Trasverse	m/min	36 /36 /30	36/ 36 / 36	36/ 36 / 36	36/ 36 / 36
Positioning Accuracy / Full Travel	mm	0.006	0.006	0.006	0.006
Repetitive Positioning Accuracy	mm	0.002	0.002	0.002	0.002
Required Air Pressure	kg/cm2	6.5	6.5	6.5	6.5
Machine Weight	kg	7000	9000	9000	15000
Floor Space	mm	1995 X 2975	2530 X 3533	2530 X 3533	2800 X 5536
Coolant Capacity (Standard)	L	290	210	210	300

AI Application inside, Hartrol Plus is the control which provides matching status with advanced features
Opitma rigid design construction assures stability, deformation-free precision year after year
Z Axis Servo motor coupled directly to ballscrew
Oversized Column and widest base design
Five Axis accuracy inspection 9 faces measurement
