DN Solutions Horizontal Machining Center DHF
DN Solutions Horizontal Machining Center DHF
Note:
The Specifications and information above-mentioned may be changed without prior notice.
Technical Specipications
DN Solutions DHF Series
| Description | Unit | DHF 8000/8000ST | DHF 8000 30000r/min / PSC |
| X-axis | mm (inch) | 1450 (57.1) | |
| Y-axis | mm (inch) | 1200 (47.2) | |
| Z-axis | mm (inch) | 1500 (59.1) | |
| Spindle nose to table center | mm (inch) | (270) ~ 1230 (-10.6 ~ 48.4) | |
| Distance from spindle nose to table top | mm (inch) | 200 ~ 1400 (7.9 ~ 55.1) | |
| Pallet size | mm (inch) | 800 x 800 (31.5 x 31.5), ø1000 (ø39.4)** | |
| Workpiece size | mm (inch) | Ø1400 x H1400 (Ø55.1 x H55.1), Ø1600 x H1400 (Ø63.0 x H55.1)** | |
| B-AXIS ROTATING SPEED** | r/min | 8 (500**) | |
| Max spindle speed | r/min | 6000 {15000, 30000}* | |
| Data specification | -100 ~ 60 | ||
| Max. torque | N·m (ft-lbs) | 960 {223, 147} (708.5 {164.6, 108.5})* | 53.4, 49.9 (39.4, 36.8) |
| X-axis | m/min (ipm) | 40 (1574.8) | |
| Y-axis | m/min (ipm) | 40 (1574.8) | |
| Z-axis | m/min (ipm) | 50 (1968.5) | |
| Max. tool moment | N·m (ft-lbs) | 34.3 (25.3) | 11.8 (8.7) |
| Tool storage capacity | ea | {90, 120, 150, 196 ~ 376}* | 80 {120, 171, 275}* |
| Tool change time (Tool-to-tool) | sec | 3.5 | 2.4 |
Features
| A-axis nodding head spindle |
| Travel (x / y / z) : 1450 / 1200 / 1500 mm (57.1 / 47.2 / 59.1 inch) |
| Max. Workpiece size : Ø1400 X H1400 mm (Ø55.1 X H55.1 inch) |
| Improved rear exit chip disposal |
| Power-pack, multi-step TSC |
| Easy chip-disposal through PSC (Programmable Shower Coolant). |
| Thermal compensation for spindle and structure |
| Y/Z dual ballscrew |
| Large working envelope with 800 mm pallet size |
| To machine high-precision, complex components with intricate shapes and features, DHF 8000 is equipped with A-axis nodding head spindles that facilitate 5-axis simultaneous machining.Dual ballscrews are applied to the X and Y axes to ensure highly-stable machining. |
