DN Solutions Double Column Machining Center DBM Series
DN Solutions Double Column Machining Center DBM Series
Note:
The Specifications and information above-mentioned may be changed without prior notice.
Technical Specipications
DN Solutions DBM Series
| Description | Unit | DBM 1525s | DBM 2030 | DBM 2040 | DBM 2540 | DBM 2550 | DBM 3050 | DBM 3060 | DBM 3080 | |
| Travel | X-axis | mm (inch) | 2800 (110.2) | 3250 (128.0) | 4250 (167.3) | 4250 (167.3) | 5250 (206.7) | 5250 (206.7) | 6250 (246.1) | 8250 (324.8) |
| Y-axis | mm (inch) | 1350 (53.1) | 2500 [+700] (98.4 [+27.6] ) | 3000 [+700] (118.1 [+27.6] ) | 3500 [+700] (137.8 [+27.6] ) | |||||
| Z-axis Travel | mm (inch) | 750 (29.5) | 800 {1100} (31.5 {43.3} ) | |||||||
| Effective width between columns | mm (inch) | 1550 (61.0) | 2000 (78.7) | 2500 (98.4) | 3000 (118.1) | |||||
| Table to Spindle Nose | mm (inch) | 250-1000 (9.8-39.4) | 1000 {1300} (39.4 {51.2} | |||||||
| Feedrate | Rapid Traverse X, Y,Z, W | m/min(ipm) | 16 / 16/ 16 /629.9 ( 629.9 /629.9) | 24/24/15 (944.9/944.9/590.6) | 20/20/15 (787.4 /787.4/590.6) | |||||
| Max. Cutting Feedrate X, Y, Z | m/min(ipm) | 8000 (315.0) | 10000/10000/10000 (393.7 / 393.7 / 393.7) | |||||||
| Table | Table Size (Width x Length) | mm(inch) | 2800 x 1250 (110.2 x 49.2) | 1500x3000 (59.1x118.1) | 1500x4000 (59.1x157.5) | 2000x4000 (78.7x157.5) | 2000x5000 (78.7x196.9) | 2500x5000 (98.4x196.9) | 2500x6000 (98.4x236.2) | 2500x8000 (98.4x315.0) |
| Load Capacity | kg (lb) | 10000 (22045.9) | 15000 (33068.9) | 17000 (37478.0) | 20000 (44091.8) | 25000 (55114.8) | 28000 (61728.5) | 32000 (70546.9) | 35000 (77160.7) | |
| T-Slot | mm(inch) | (7-160 x 22H8) | 24H8 (28H8) (0.94H8 (1.1H8) ) | |||||||
| Spindle | Spindle speed | r/min | 40 {8,60} | 6000 {8000} | ||||||
| Tool Shank | - | BT / CAT / DIN 50 | BT 50 {CAT 50, DIN 50} | |||||||
| Ram Size | mm (inch) | 380 x 380 (15.0 x 15.0) | ||||||||
| ATC | Tool Storage Capacity | ea | 40 {60, 90,120} | |||||||
| Max. Tool Diameter | mm (inch) | 125 (200) (4.9 (7.9)) | 130 [250] (5.1 [9.8]) | |||||||
| Max. Tool Length | mm (inch) | 500 (19.7) | 400 (15.7) | |||||||
| Max. Tool Moment | N·m (ft-lbs) | 12.74 (9.4) | 35.28 (26) | |||||||
| Machine Size | Machine Height | mm (inch) | 4360 (171.7) | 5100 {5700} (200.8 {224.4}) | ||||||
| Floor Space (Machine only) | mm (inch) | 8220 x 4395 (323.6 x 173.0) | 7950X11900 (313.0x468.5) | 7950X13600 (313.0x535.4) | 8200x13600 (322.8x535.4) | 8200x15600 (322.8x614.2) | 8600X15900 (338.6X626.0) | 8600X18200 (338.6X716.5) | 8900X22600 (305.4x889.8) | |
| Machine Weight | kg (lb) | 28000 (61728.5) | 33000 (72751.5) | 37000 (81569.8) | 42000 (92592.8) | 46000 (101411.1) | 50000 (110229.5) | 55000 (121252.5) | 70000 (154323.6) | |
Features
| The best specifications in its class – effective widthbetween columns has been further extended by 200 mm(7.9 inch) for increased machining capacity. |
| A variety of different ram spindle specifications and a wide range of auto-change attachments support many types of machining applications,from simultaneous 5 axis rocessing of dies/molds to heavy duty cutting |
| Adoption of the DSQ I/II/III functions,highspeed rapid traverse and cutting feedrate, highload table capacity |
| X/Y/Z axes ball screw shaft cooling as options enables the machining of high-accuracy and high-speed molds and general parts. |
| The DCM II series provides a support system for 5face machining of large and heavy workpieces, easy pattern cycles, work load counter control,automatic feed control, and process monitoring function. |
| Designed for large work pieces, the machine enables long-term, heavy-duty cutting with stable machining accuracy. |
| The best specifications in its class – effective width between columns has been further extended by 200 mm (7.9 inch) for increased machining capacity. |
